Labs

Home » UG Programme » E & TC » Learning Infrastructure » Labs

Lab no: MB 303
Equipment Names:
  1. Universal IC Tester Kitek DICT-04
  2. Digital Storage Oscilloscopes GW Instek GDS1102B 2 Channel100MHz
  3. Electronic Test & Measuring Instrument
  4. Digital Trainer Kits
Lab no: MB 304
Equipment Names:
  1. Spectrum Analyzer (GW INSTEK) 830 + TG (2 nos.)
  2. Digital Storage Oscilloscope (GW Instek) GDA1104B 4 Channel 100MHz (2 nos.)
  3. Digital Storage Oscilloscope (Tektronix 4 Ch., 100 MHz, 1GS/s ) (2 nos)
  4. Digital Storage Oscilloscope (Tektronix 2 Ch., 60 MHz, 1GS/s ) (4nos.)
  5. Spectrum Analyzer (Agilent Technologies) 9kHz – 3GHZ Agilent (2nos.)
  6. Electronic Test & Measuring Instrument
  7. Communication Trainer Boards
Lab no: MB 305
Equipment Names:
  1. JDSU Optical Time Domain Reflectometer – MTS4000 – 1 no.
  2. Satellite Training Lab Amitec Make 5.8 GHz C&S Band SCT 06
  3. Microwave Test Bench Klystron & Gunn Based
  4. Falcon Electro Tek Link A Fiber Optic Communication Trainer kit
  5. Software – Ladder Programming Software for Allen-Bradley PLC Model MICROLOGIX-1200
  6. Electronic Test & Measuring Instruments
  7. Power Electronics, Fiber Optics & Communication Trainer Boards
  8. National Instruments NI LabVIEW Academic Premium Suite Software – 1 no., National Instruments NI ELVIS II Hardware – 1 no, (NI Digital Electronics FPGA Board addon ELVIS II, Free scale (HCS12) Microcontroller Prototype Board add on to ELVIS II, NI USB multifunction DAQ 6008 card)
Lab no: MB 306
Equipment Names:
  1. Crescent PCB Development Setup
  2. AMITEC 5MHz -2GHz antenna training system
  3. B&R Automation PLC Program Logic Control
  4. Software – National Instruments MultiSIM + multiMCU + Ultiboard 5 user
  5. Agilent Technologies Multi-Purpose Lab Station a- Mixed Signal Oscilloscope, b-Triple Output GPIB Power Supply, c- 6 1/2 Digital Multimeter, d- 20MHz Arbitrary Function Generator, e- GPIB USB Adapter f-Instrumentation Trainer kit
  6. Digital Storage Oscilloscope GW Instek GDS1102B 2 Channel100MHz
  7. Electronic Test & Measuring Instrument
  8. Trainer Boards
Lab no: MB 307A
Equipment Names:
  1. Desktop PC I7 Processor 11 Gen , 16GB RAM, 240 WDS SSD, Lenovo 24″ (8 nos.)
  2. Desktop PC I5 12 Gen, 16GB RAM, SSD 500 WD, Graphics card, Lenovo 24″ (11 nos.)
  3. Trainer / Development Boards
  4. Software – Eclipse, MATLAB Campus wide 2021A / Latest – N user MathWorks Inc, Windows, Ubuntu
Lab no: MB 303
Equipment Names:
  1. Universal IC Tester Kitek DICT-04
  2. Digital Storage Oscilloscopes GW Instek GDS1102B 2 Channel100MHz
  3. Electronic Test & Measuring Instrument
  4. Digital Trainer Kits
Lab no: MB 308A
Equipment Names:
  1. Desktop PC I7 Processor 11 Gen, 16GB RAM, 240 WD SSD, Lenovo 24″
  2. Desktop PC I5 12 Gen, 16GB RAM, SSD 500 WD, Lenovo 24″
  3. FPGA Trainer Boards
  4. Software – Xilinx, Eclipse, MATLAB Campus wide 2021A / Latest – N user MathWorks Inc, Windows, Ubuntu
  5. B&R ETA & Robotic kits
Lab no: MB 308B
Equipment Names:
  1. Software MATLAB Campus wide 2021A / Latest – N user MathWorks Inc
  2. Desktop PC I7 Processor 11 Gen, 16GB RAM, 240 WDS SSD, Lenovo 24″ (6 nos.)
  3. Desktop PC I5 12 Gen ASUS M/B, 16GB RAM, SSD 500 WD, Lenovo 24″ (11 nos.)
  4. Intel Core I 5 2.8 GHz/6MB, 8 GB RAM DDR4, 1 TB Hard disk (9 nos.)
  5. Software – B&R PLC Automation Studio License
  6. Software – MultiSIM + multiMCU + Ultiboard 5 user
  7. Evaluation & Training for Automation Kit Model ETA 1000.0100-1
  8. Trainer / Development Boards
  9. Software – Windows, Ubuntu, Cadence Design Suite
Lab no: MB 603
Equipment Names:
  1. Electronic Test & Measuring Instrument
  2. Inhouse Basic electronics experimental kits
  3. Basic Electronic components
  4. Digital Trainer kits
